Description
FFV make Hand lever valves are widely used to manually control the motion of cylinders within the stroke ranges These are available in Various Type such as 3/2 way,5/2 way,5/3 way & 4-port rotary type valves.Type are also determine as Pressure at Center or Exhaust at Center.Mounting of spring are centered type or offset spring types, With model of detent spring & spring return type.
Features
- Compact Size,Light weight,aluminum bodies and Buna-N seals
- Suitable for panel mounting
- Mounting provision for individual unit
- High pressure and flow capability for maximum cost-effectiveness
- Maximize machine life due quiet low vibration
Specification:
Size
1/4",3/8" & 1/2"
Body
Aluminium Anodized
Seals
Nitrile
Pressure
up to 10 Kg
Temperature
up to 60°C
Media
Compressed air, Filtered air, Dry & Lubricated air
